Storyline Link

1. Ask students to reread 3.1.R1: Design a Playground which they read in Lesson 1: Movement on the Playground. Ask the class, “What are the concepts we have learned in this unit?” Direct students to review their science notebook entries (from Lessons 1–4) on the cause and effect of force and motion on the playground. Based on your assessment from Lesson 4: Balanced and Unbalanced Forces, discuss some of the major things students now understand regarding forces that caused objects to move, changed the rate they moved, or the direction in which they moved. Emphasize areas that students were not clear on in the assessment. Chart these ideas. ESRs: I learned that a force acts on an object that stays still or moves. I learned if forces are unbalanced then there will be a change in direction or speed. I learned that gravity is a force that pulls things down. I learned that identifying a pattern in motion can help predict future motion.
2. Tell the class, “Your challenge is to use these science concepts about force and motion and the engineering process to design and build a model for a new playground structure or activity. You must also explain its function. To get started on thinking about our design, let’s look at the district’s architect’s blueprint of the new playground area.”
3. Show 3.5.R1: Map of New Playground on the document camera, or draw it on chart paper. Point out where the new basketball court, soccer field, and tug-of-war areas will be. Remind the class that they worked on prototypes for designs for these areas earlier in the lessons.
4. Point out the area on 3.5.R1: Map of New Playground where the new playground space is located. Explain that this is the area where they will be creating activities or structures to be built. This area can be used for one large activity/structure or multiple activities/structures.
5. Take students out to the playground and re-define the challenge. Have them envision what the design of the new structure or activity might be and how it will be located in the playground space. Ask them to write any questions they have about the challenge in their science notebook. Encourage them to write questions that will help them with their design.

   Possible student-driven questions:

   • What can we design it to do?
   • Does it have to have _____? _____?
   • Should/Can there be moving parts in the structure?
   • Should/Can there be more than _____ sections (or parts) in the structural design?
   • Should/Will the different parts of the structure work together?
   • Is there a purpose in the design that supports physical education or science goals?
   • How will what I have learned about force and motion influence my design?
6. On another page in their science notebook, have students make a quick diagram of their ideas for the new playground structures or activities.
7. Return to the classroom and have students share their questions as you write them on a chart. Then, give them time to explain some of their design ideas.

TEACHER NOTE

Explain to students that the questions about size, materials, and time will be answered during your explanation of the engineering design process. Also explain that they will work to figure out the answers to many of their other questions during this lesson.

8. Introduce the 3.5.R2: EiE Engineering Design Process. In the goal area ask students to write the challenge: Design a new playground structure or activity that includes force and motion.

TEACHER NOTE

3.5.R2: EiE Engineering Design Process is an example of the engineering design process by Engineering is Elementary (EiE), a division of the Museum of Science, Boston (https://www.eie.org). 3.5.R3: NGSS Engineering Design Process is another example of the engineering design process taken from the NGSS Science Frameworks (Appendix I).

Note: The design process is called out in ETS1.A [Possible solutions to a problem are limited by available materials and resources (constraints). The success of a designed solution is determined by considering the desired features of a solution (criteria). Different proposals can be compared on the basis of how well each one meets the specified criteria for success or how well each takes the constraints into account. (3-5-ETS1-1)]

9. Begin with the ASK circle. Guide students with the process of asking questions and defining problems, such as: “What do you know? What do you need to do? What questions do you have about the activity they will complete?” (Refer to the chart made earlier, and if necessary, add more questions.)
10. Explain that the school administration has decided on criteria which the playground design needs to meet. All criteria must be met or the design will not be accepted. Display the top of 3.5.R4: Criteria and Constraints on the document camera and conduct a discussion for each of the criteria for the project.

    The design and explanation must include:

    1. At least two different places where forces will be used to produce movement. The explanation must describe those forces as balanced and/or unbalanced.
       • Ask students for an example. ESRs: movement with an unbalanced force of a push or a pull (e.g., dragging an object; hitting/kicking, bouncing an object)
    2. The strength and direction of the forces on the object.
       • Ask students for examples. ESRs: a hand throwing a basketball straight at a basketball hoop, a strong kick of a soccer ball that travels a big distance
    3. A change in either direction of motion or distance.
       • Ask students for examples. ESRs: one person kicks a soccer ball a distance toward another player who kicks the ball farther down the soccer field; a basketball thrown upward toward the hoop hits the backstop before falling into the hoop and toward the ground.
    4. The pattern of motion that would be observed.
       • Ask students for examples. ESRs: a merry-go-round moves as a result of a force, and the pattern of the speed depends on the strength of the force; every time a soccer ball is kicked very weakly, it doesn’t go very far.
    5. Motivate students to want to use the playground structure or activity.
       • Ask students for examples. ESRs: a climbing wall that looks like a real mountainside, a tall merry-go-round that has swings underneath it, etc.
11. Explain that in addition to criteria, engineers must contend with a variety of limitations or constraints. These constraints describe the conditions under which the design must be done. Constraints are things like time to complete the project, size, weight, use of materials, and budgets.
12. Display the bottom of 3.5.R4: Criteria and Constraints on the document camera and review the constraints for the project:
    1. Materials are limited to what is available on the supply table.
       • Show students the materials on the supply table.
    2. The prototype of the playground structure or activity size must be limited to the size of your desktop.
       • Show students the area of the desktop.
    3. The prototype of the playground structure or activity must be designed in a specified numbers of class periods.
       • Tell students how many class periods they will have to design their prototypes.

13. Point to the IMAGINE circle on 3.5.R2: EiE Engineering Design Process. Explain that this is the time when engineers use their imaginations to help them brainstorm as many possible design solutions as they can.
14. Give time for students to individually brainstorm ideas that they would like to design, reminding them of the criteria. Have them record their ideas in their science notebook. Remind them that this is a “dream session” in which they can use force, motion, and direction symbols.
15. Divide the class into design teams. One way to do this is to have students share the type of design they thought about (e.g., design an activity; design a structure for students to climb or slide; design obstacle course for climbing, jumping, rolling) and then see if there are others who have a similar idea. Group those students together. Another idea is to just number students off into groups of 4 and let them share their ideas.
16. Point to the PLAN circle on 3.5.R2: EiE Engineering Design Process. Ask group members to share their ideas with each other. It is okay to continue to brainstorm or build on each other’s ideas. However, their goal is to come to agreement on one possible design idea.
17. Once the team has decided on one possible design idea, remind teams of the criteria. Encourage students to include what they know about force and motion to explain their design. (See Teacher Note below.)
18. Have the teams review the constraints to see if they need to adjust any of their thinking.
19. Finally ask teams to review the materials that are available for building and determine if they need to make any changes. Then ask teams to agree on what materials to use.
20. Distribute poster paper to each group and ask them to create a team design diagram.
21. Have groups share their plan and materials list with you for approval and gather their supplies.

TEACHER NOTE

When students share their plan, one thing to have them explain is what type of force will be used (balanced, unbalanced); how the forces lead to motion (cause and effect); as well as making sure they are showing the predicted direction and strength of the forces with arrows. This is an important part of their design, as it makes them reflect on what they’ve learned about forces and motion. This can be used as a point of formative assessment.

TEACHER NOTE

This activity allows for integrating mathematics, and you can choose to put a “price” on the materials, and give groups a limit of how much they can “spend.” It would tie in to 3.NBT.A.2: Use place value understanding and properties of operations to perform multidigit arithmetic.

TEACHER NOTE

For the purposes of this lesson, a physical model can be either building a model with real stuff or making a detailed diagram.

22. Point to the CREATE circle on the chart of 3.5.R2: EiE Engineering Design Process. Ask teams to build a model of their playground structure or activity based on their design plan.
23. Ask teams to test the model, doing several trials and recording their observations and data in their science notebook.
24. Ask teams to write their explanation of how their design met all the criteria.

25. Have teams share results and explain their design: “What were they trying to do? What results did they get? Did the design stay within the constraints? Did it meet the criteria? Does it have an explanation based on the science concepts of force and motion?”

TEACHER NOTE

The goal is for the teams to present their design and its effectiveness for solving the problem. It would be best if all groups could hear from each other, but this is time consuming. One option is to partner groups, or put them in trios so that they hear at least 1 or 2 other groups reporting. Another way is to do a gallery walk where students visit different teams. One member of each team remains with the design to share results; the rest of the team travels and then returns and shares what they learned.

It is a good idea to take pictures of the students’ prototypes at this point. When students do revisions to their models, it is helpful for the students to have documentation of their initial model for reflection.

Students may need scaffolding to stay on topic and to generate questions of each other that are helpful. You can choose to offer some sentence frames that show how engineers talk to one another about designs:

For sharing ideas:

• We observed _____.
• Our data shows _____.
• We think _____ because _____.
• We are wondering about _____.

For responding to others’ ideas:

• Can you explain _____ to me?
• Why do you think _____?
• What evidence do you have….?
• I agree with _____ because _____.
• I respectfully disagree with _____ because _____.
26. Bring the class together for a final discussion of what they found out about each other’s designs.

TEACHER NOTE

Explain that this engineering design process is a simplified version built on specific components within a more complex design process. This is called out in the standard ETS1.B: At whatever stage, communicating with peers about proposed solutions is an important part of the design process, and shared ideas can lead to improved designs.

27. Point to the IMPROVE circle on the chart of 3.5.R2: EiE Engineering Design Process. Explain that engineers often try to improve on a design. Ask students to think of things (or technologies) that have been improved in their lives. ESRs: many versions of video game boxes; improved cell phones; bigger, thinner TVs.

TEACHER NOTE

Point out to students that engineers strive to improve existing technologies or develop new ones to increase their benefits (to man, living creatures, or the environment), decrease known risks, and to meet societal demands. If you are able to show an example of an old, big cell phone (or a flip phone) and a newer version, this real object can help students connect with this concept.

28. Request teams to think of and discuss what they learned from the other teams’ designs. Say, “Can you use any ideas from other projects to make your model work better?” Have the teams brainstorm new ideas to improve their design and support their brainstorming with reasoning.
29. Distribute chart paper (or have students return to their original design) for students to refine or modify their design plan. Have students add an explanation of the changes they decided to make in their design and from where or whom they got the idea.

    Provide sentence frames if necessary:

    • After discussing and sharing ideas with _____, we decided to improve our design by _____.
    • After observing other teams’ proposed solutions, we decided to improve our design by _____.
30. Then, have students post their modified/revised designs, and have the groups do a gallery walk. During the gallery walk, students walk around the room evaluating their peers’ designs and use the sticky notes to leave comments about the design.
    1. They may ask a question or request clarification on yellow sticky notes.
    2. They may write an observation on green sticky notes.
    3. They may make a suggestion for improvement on orange sticky notes.

TEACHER NOTE

Remind students to use the sentence frames that show how engineers talk (from Step 25).

31. Once all teams have had a chance to leave their critiques, give teams time to discuss the feedback they received, and then rebuild or modify their model. Allow time for students to test it again, if they wish.
32. Ask teams to write an evaluation of their new design in their science notebook. “Did it work better? What is the evidence?”

33. Ask each student to review his or her final design and evaluate if it:
    1. meets the design specifications of the original plan AND
    2. was tested and worked.
34. Direct students to write a letter to the school board that includes the diagram of their finalized piece of playground structure or activity. The letter must explain:
    • how it works and how students would use it.
    • why their design should be chosen for a new playground structure or activity based on evidence that it uses force and motion.
    • how the causal relationship between the direction and strength of forces are used in their playground structure or activity by creating a change in motion.
    • how this created balanced or unbalanced forces and what patterns of motion were observed.
    • how they used the engineering design process to create, test, and revise their solution.
    • what they learned along the way.

TEACHER NOTE

Writing a letter gives students an opportunity to communicate scientific information in a written format, including various forms of media as well as tables, diagrams, and charts which is a grade-level element of the SEP “Obtaining, Evaluating, and Communicating Information.” You could add an oral presentation to this assignment as well. Writing a letter of this type also supports the SEP of Constructing Explanations.

You can use the letter to assess students’ knowledge of the three dimensions they used to solve the problem and their use of the engineering design process to explain change through the relationships (cause and effect) between forces and motion. Use 3.5.R5: Playground Rubric for this assessment.
